| Printhead: | Sixteen on-demand piezo heads in a staggered array |
| Print resolution | 600 x 600dpi, 600 x 1,200dpi, 1,200 x 1,200dpi |
| Print speed (4 color mode) | up to 2,152.78 SqFt/Hr (200.0 m2/h) |
| Maximum Print Area: | 98.443″ x 122.05″ (2,550 mm x 3150 mm) |
| Maximum media width: | 63.8″ (1620 mm) |
| Maximum media thickness | up to 2.36″ (60 mm) |
| Maximum Media Weight: | 10 lb./ft2 (50 kg/m2) |
| Ink Type/Color: | Rigid: LH-100, Flexible: LUS-120, LUS-150 |
| Interface: | Ethernet 10,000 BASE-T |
| Power supply: | AC 200 – 240 V, 50/60 Hz |
| Power consumption: | Less than 4.8kWhr x3 |
| Operational environment: | Temperature 68° – 86° F (15-30° C) Humidity: 35–65 % RH (Non condensing) |
| Dimensions (W × D × H): | 213” x 191” x 67” (5400mm x 4850mm x 1700mm) |
| Weight: | 3,527 lbs. (1,600 kg) |
The JFX600 Series wide format flatbed printers boast high speed production with full board printing in under 60 seconds. With their quick registration system, semi-automated maintenance, full board and extra-large print areas of 8’ x 4’ and 8’x10’, they fit as perfectly in a high-volume packaging or POP shop as they do in specialized architectural printing and interior design shops.
| LH-100 UV curable ink 1L Bottle | CYAN: LH100-C-BA |
|---|---|
| UV curable ink (LUS-120) 1L Bottle | CYAN: LUS12-C-BA |
| UV curable ink (LUS-150) 1L Bottle | CYAN: LUS15-C-BA |
| UV Primer (PR-200) 1L Bottle | PRIMER: PR200-Z-BA |
