JFX600-2513

Printhead: Sixteen on-demand piezo heads in a staggered array
Print resolution 600 x 600dpi, 600 x 1,200dpi, 1,200 x 1,200dpi
Print speed (4 color mode) up to 2,152.78 SqFt/Hr (200.0 m2/h)
Maximum Print Area: 98.43″ x 51.18″ (2,500 mm x 1,300 mm)
Maximum media width: 63.8″ (1620 mm)
Maximum media thickness up to 2.36″ (60 mm)
Maximum Media Weight: 10 lb./ft2 (50 kg/m2)
Ink Type/Color: Rigid: LH-100, Flexible: LUS-120, LUS-150
Interface: Ethernet 10,000 BASE-T
Power supply: AC 200 – 240 V, 50/60 Hz
Power consumption: Less than 4.8kWhr x3
Operational environment: Temperature 68° – 86° F (15-30° C)
Humidity: 35–65 % RH (Non condensing)
Dimensions (W × D × H): 207.48″ x 110.24″ x 62.99″ (5,300×2,850×1,700mm)
Weight: 2,645.5 lbs. (1,200 kg)



Printer Specifications

Description

The JFX600 Series wide format flatbed printers boast high speed production with full board printing in under 60 seconds. With their quick registration system, semi-automated maintenance, full board and extra-large print areas of 8’ x 4’ and 8’x10’, they fit as perfectly in a high-volume packaging or POP shop as they do in specialized architectural printing and interior design shops.

Additional information

LH-100 UV curable ink 1L Bottle

CYAN: LH100-C-BA
MAGENTA: LH100-M-BA
YELLOW: LH100-Y-BA
BLACK: LH100-K-BA
WHITE: LH100-W-BA
CLEAR: LH100-CL-BA

UV curable ink (LUS-120)

CYAN: LUS12-C-BA
MAGENTA: LUS12-M-BA
YELLOW: LUS12-Y-BA
BLACK: LUS12-K-BA
WHITE: LUS12-W-BA
CLEAR: LUS12-CL-BA

UV curable ink (LUS-150)

CYAN: LUS15-C-BA
MAGENTA: LUS15-M-BA
YELLOW: LUS15-Y-BA
BLACK: LUS15-K-BA
WHITE: LUS15-W-BA
CLEAR: (Use LH-100)

UV Primer (PR-200)

PRIMER: PR200-Z-BA
